SMHS Fish Feed Extruder
Extruder for aqua feed and pet food lines, from 0.8 to 5 t/h, with a dual-axis differential conditioner for full regulation and high efficiency.
- 0.8–5 t/h
- SMHS series
- Installation & spares
45–185 kW
Main motor power
0.8–5 t/h
Extrusion capacity
45–185 kW
Main motor power
4 models
SMHS128 to SMHS185
Aqua & pet
Feed types
Working Principle
Finely ground and mixed raw materials are conditioned with steam and then forced along the barrel by the screw. Heat, pressure and shear cook the starch; as the product leaves the die it expands and is cut into pellets, which go on to the dryer, coater and cooler.
Key features
- Reasonable shear forces in each zone of the chamber
- Higher yield while keeping high quality
- Dual-axis differential quality regulator
- Full regulation and high efficiency
- Built to international standards
- Stable running with reduced noise
Technical Data
Figures from the SEMZON catalogue. Our engineers confirm the final model for your product and capacity.
| Model | Capacity (t/h) | Main power (kW) | Feeder power (kW) | Conditioner power (kW) |
|---|---|---|---|---|
| SMHS128 | 0.8–1.2 | 45 / 55 | 1.5 | 3 |
| SMHS135 | 1.5–2.0 | 55 / 75 | 1.5 | 4 |
| SMHS165 | 3.0–5.0 | 132 / 160 | 1.5 | 4 |
| SMHS185 | 4.0–5.0 | 160 / 185 | 1.5 | 5.5 |
Where It Is Used
Often Used Together
Common
Questions
Straight answers to the questions our engineers hear most about the SMHS Fish Feed Extruder.
Still have questions?
Talk directly with our engineering team for a tailored consultation.
What is the price of a fish feed extruder in Pakistan?
It depends on the model (SMHS128 to SMHS185) and the rest of the line — pre-grinding, mixing, drying, coating and cooling. Tell us your target output in t/h and we will quote the extruder or a complete line.
What else is needed for a fish feed plant?
Raw materials such as fish meal, soybean meal and corn are pre-ground to 300–500 µm, mixed, extruded, then dried, coated and cooled. We design the whole line around the extruder.
Can it make pet food?
Yes. The same extrusion technology is used for extruded fish feed and pet food production lines.
